400 series Vario Built-in freezer 212.5 x 60.3 cm soft close flat hingeRF463505
1 / 18
400 series Vario Built-in freezer 212.5 x 60.3 cm soft close flat hingeRF463505
Find a local Dealer
Technical Overview
Energy Star Rating
3 Energy Star
Automatic defrosting
Freezer
Home Connect Footnote 1 Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com. End of the footnote
Yes
Specifications
Stainless steel interior with solid anthracite aluminium elements
Warm white and glare-free LED light spots
Opening assist for door with two options:
1. Push-to-open function for integration into handleless furniture front 2. Pull-to-open function to facilitate opening the door using a handle
The drawers in the RC and RF models are positioned at the same height. With side-by-side installation, the glass shelves and door racks can be aligned on the same level
Flat stainless steel inner door, full-length
Integrated ice maker with fixed inlet water connection
Proximity sensor for ice and water dispenser
Illuminated dispenser for ice cubes, crushed ice and chilled water
TFT touch display
Total volume 359 litres
TFT touch display operation.
Clear text display.
Touch key operation for ice and water dispenser.
3.5 Energy star rating
Energy consumption 353 kWh
Noise level 38 dB (re 1 pW).
Dynamic cold air distribution.
Automatic defrosting with defrost water evaporation.
When rest mode is active, the appliance can only be opened using a handle.
Open-door and malfunction alarm.
Home network integration for digital services (Home Connect) wireless via WiFi.
The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.
No-frost technology with fast freezing at -30 °C.
Temperature adjustable from -14 °C to -24 °C.
Freezing capacity 14 kg/24 h.
Storage time after a malfunction 10 h.
4 safety glass shelves, white glass, 2 of which are individually height adjustable.
2 fully extendable drawers with transparent front.
Warm white LED lighting.
Proximity sensor for automatic activation of light and touch keys for ice and water dispenser.
Integrated, with fixed inlet water connection.
Particle filter for water inlet, integrated in ventilation grille area.
Can be switched off.
Ice cube production approx. 1.4 kg/24 h.
Ice cubes and crushed ice.
Removable ice storage container with approx. 3.2 kg capacity.
Ice water supply approx. 1.5 litres.
Flat hinge.
Door opening angle of 115°, fixable at 90°.
Max. door panel weight 67 kg.
Shut-off valve for water connection must be planned next to the appliance and always be accessible.
If the water pressure exceeds 0.8 MPa (8 bar), connect pressure relief valve between water tap and hose set.
Total connected load 0.300 KW.
Connecting cable 3.0 m, detachable.
Water inlet.
Supply hose 2.9 m with 3/4 " connection.
Water pressure 2 to 8 bar.
