200 Series Vario downdraft ventilation 15 cm BlackVL200120
Replacement for
VL041115
1 / 29
+ 14
200 Series Vario downdraft ventilation 15 cm BlackVL200120
Replacement for
VL041115
Find a local Dealer
Technical Overview
Installation typology
Built-in
Width of appliance
15 cm
Main colour of product
Black
Sound power level extraction (max)
71 dB
Maximum output air extraction
550 m³/h
Type of extraction
air extraction / air recirculation
Home Connect Footnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Specifications
Can be combined with the cooktops of the Vario 200 series to a harmonic unity
Highly efficient ventilation system at the cooktop integrated in the worktop
Function for automatic, sensor-controlled power adjustment depending on the build-up of cooking vapours
Low planning and installation effort
Air extraction or air recirculation system
Power levels depend on the remote fan unit.
Control knobs with illuminated ring.
3 electronically controlled power levels and 1 intensive mode.
Large-scale metal grease filter with high grease absorption.
Grease filter and activated charcoal filter saturation indicator.
Airflow-optimised interior for efficient air circulation.
Interval ventilation, 6 min.
Enamelled ventilation grille, dishwasher-safe.
Air exhaust bend included in delivery.
Overflow 250 ml capacity.
Sound level min/max (intensive) according to EN 61591: 56 / 76 dB(A)
For each VL one remote fan unit is recommended.
Maximum cooktop width between two VL 60 cm.
If installed next to gas appliances, the ventilation moulding LS 041 001 is recommended to ensure maximum performance of the cooktop.
When having installed the ventilation moulding LS 041 001 the wok pan WP 400 001 can not be used.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Connecting cable 1.7 m between VL and remote fan unit.
